Description

Standard Features

• 10 tons/hour transport, dosing and discharge capacity.
• Filling weighing system supported by 24-bit ADC.
• Stainless class III load cells,
• Batch filling, discharge or continuous filling, loss in weight discharge.
• AISI 304 stainless filling hopper
• Dry type pneumatic conditioners, pistons, valves and fittings.
• All surfaces are trated and coated by powder die in accordance to food codex.
• Pneumatic butterfly valve and vibration unit
• Polyester fabric filter, compressed air tank and pulse valves
• Chassis with height and balance adjustment.
• Modular and easy installable scale body and scale chassis.
• Aestetic, low maintenance required, stabile running

Optional Propoerties

• Planetary dust-tight discharge throat
• Pneumatic anti-dust stainless cover specially prepared for discharging into the dough bowl.
• Stainless dosing screw
