Description

Standard Features

Product Type   Bakliyat
Yoğunluk (Un) 0,75 Kg/m³
Weighing Range 10 – 25 Kg
Weighing Accuracy ± % 0,1
Surge Bin Capacity 575 Litre
Hopper Capacity 70 Litre
Output Capacity 50 Kg 25 Kg 11,47 Ton/Saat
Çıkış Kapasitesi 10 Kg 5 Ton/Saat
Tartım Paket Adedi 25 Kg 470 Torba/Saat
Tartım Paket Adedi 10 Kg 500 Torba/Saat
Air Pressure 6 – 8 Bar
• Air Consumption 21.6 litre/dk
Power Consumption 1,12 kW/Saat

• Electronic filling control system supported with 24 bit ADC.

• Equipped with Class III type stainless steel loadcells.
•High speed belt conveyor.
• Dry type pneumatic conditioners, pistons, valves and fittings.
• PLC controlled power and command control system cubicles.
• Equipped with touch screen user interface system
• Easy adjustable set value entry by operatör.
• Programmable bag amount set.
• Easy weight calibration and multy recipe application according to product type.
• All surfaces are trated and coated by powder die in accordance to food codex.
• 960 lt capacity, fill end discharge level controlled material entry stock bin.
• High discharging capacity, high leakage insulated weigher bin. It is connected to loadcells by adjustable rods.
• At 50 kg filling mode 5-6 bag filling amount in a minute.
• Speed controlled transfer band with hydrolic manual height adjuster.
• Height adjustable chassis foots
• Modular and easy installable scale body and scale chassis.
• Aestetic, low maintenance required, stabile running
• Height adjustable sewing column.
