Description
| Product Code | BS.SFSS.05.10 |
| Weighing Range | 5-10 Kg |
| Weighing Accuracy | ±%0.2 |
| Bag Type | Polypropylene Bag |
| Weighing Capacity | 5 Kg – 450 Bags/Hour, 10 Kg – 400 Bags/Hour |
| Air Pressure | 5-6 Bar |
| Air Consumption | 40 Litre/Minute |
| Power Supply | 3 Ph,380 VAC /50-60 Hz |
| Total Power | 1.48 Kw |
| Feeding Type | Auger |
Standard Features
• Electronic filling control system supported with 24 bit ADC.
• Equipped with Class III type stainless steel loadcells.
• Dry type pneumatic conditioners, pistons, valves and fittings.
• PLC controlled power and command control system cubicles.
• Equipped with touch screen user interface system
• Easy adjustable set value entry by operator.
• Programmable bag amount set.
• Easy weight calibration and multy recipe application according to product type.
• All surfaces are trated and coated by powder die in accordance to food codex.
• 400 lt capacity, fill end discharge level controlled material entry stock bin.
• High discharging capacity, high leakage insulated weigher bin. It is connected to loadcells by adjustable rods.
• At 5 kg filling mode 10 bag filling amount in a minute.
• Speed controlled transfer band with hydrolic manual height adjuster.
• Height adjustable chassis foots
• Modular and easy installable scale body and scale chassis.
• Aestetic, low maintenance required, stabile running
• Height adjustable sewing column.
